FSTG-XSNIR966-910
€260,00
Quantity based pricing table
Min | Max | Unit Price |
---|---|---|
1 | 9 | € 260.00 |
10 | and more | € 140.00 |
Need help?
For further information or to request a quotation please contact us.
FSTG-XSNIR966-910
Fused silica transmission grating technology enables high resolution, high efficiency gratings that are ideal for compact spectrometers.
Lithographic or holographic stepper patterning technology combines the highest quality of patterning with the reproducibility and cost level of replicated gratings
100% Fused silica gratings provide unbeatable temperature stability, environmental tolerance and power damage threshold – also in the UV
Grating resolutions up to ~3000 l/mm
High diffraction efficiency with high dispersion
Low polarization dependence (PDL) over broad spectral ranges
Combined wavelength dispersion and folding elements
Multiple prototyping, small and high volume production technologies
Class 10 cleanroom production ensures low noise and high cleanliness – as well as a controlled environment for our metrology capabilities
Extensive grating metrology including proprietary period measurement systems, a versatile diffraction efficiency measurement system, a high resolution defect inspection system as well as AFM/SEM ensuring that agreed upon specifications are fulfilled
Parameter | Specification |
---|---|
Grating technology | Surface relief, etched transmission gratings |
Grating resolution | 966 l/mm |
Illumination wavelength range | 475 nm - 1100 nm |
Angle of incidence | 17.3 deg |
Materials | Fused silica |
Chip size | 4 mm x 4 mm |
Grating area | 5 mm x 7 mm |
Chip thickness | 0.625 mm |
Download Product Sheets
We are happy to discuss your requirements for customized gratings. Use the forms at the bottom of the page to specify your requirements for a discussion or quotation.
