Fused silica transmission gratings
Production technology: Holostepper (Holographic stepper) and RIE etching
C-band is defined as 1525 nm – 1565 nm (but can be OEM customized)
100% dielectric materials – No polymers, epoxies, gelatins or metals
Grating chip thickness: 0.625 mm
Maximum operating temperature at least 500° C
Packaging: Packed in semiconductor grade Gelpak containers, sealed in class 10 cleanroom
Download Product Sheets
Ibsen Product Sheets – PING-600-052
We are also happy to work with you to design an optimal grating for your OEM requirements. Use the forms at the bottom of the page to specify your requirements for a discussion or quotation.
— OR —
Quantity based pricing table
For further information or to request a quotation please contact us.
Do you want to discuss your grating project over the phone? Please fill out the below form, and we will contact you.
I would like to receive a quotation on the following PING grating
